Filtreau drum filter (25M3 /HR) Inc 40W amalgam
Filtreau drum filter (25M3 /HR) Inc 40W amalgam
Introducing the Filtreau Drum Filter (Gravity) - an efficient and reliable filtration system designed for optimal water clarity and ease of use. This gravity-fed filter is equipped with a powerful 40W amalgam UV-C lamp and offers a maximum flow rate of 20 m³/h, ensuring exceptional performance for your pond.
The Filtreau Drum Filter features two 110mm inlets and one 110mm outlet, allowing for a smooth water flow and efficient filtration. Made from high-quality materials such as PA, stainless steel 316, FPM seal, and high-pressure PVC, this filter is built to withstand the demands of continuous operation.
With a diameter of 38x40cm, the drum provides ample filtration capacity while maintaining a compact design. The gearbox, equipped with a 27Nm slip clutch, ensures reliable and precise operation, minimizing the risk of any disruptions.
The screen panels of the Filtreau Drum Filter are made of 70-micron stainless steel 316, effectively capturing debris and impurities for crystal-clear water. The flat jet nozzles and high-pressure PVC spray bar enhance the filtration process, distributing water evenly for optimal cleaning performance.
The filter comes with a control box featuring IP44 protection, ensuring durability and safety even in demanding environments. The manual control push button allows for easy operation and monitoring of the filtration system.
With a body dimension of 79x48x54cm (total length 79cm, including waste collector), the Filtreau Drum Filter is designed for convenient installation and maintenance. All components are easily replaceable, providing hassle-free maintenance and quick changes when needed.
Rest assured with the included 2-year warranty on all parts (excluding screen elements) and the CE approval for both the UV-C and Drum body. The filter also features an hours counter and replace message, allowing you to monitor the usage of the amalgam UV-C lamp and ensure timely replacements for optimal performance.
Choose the Filtreau Drum Filter (Gravity) for superior filtration and reliable performance. Enhance the clarity and quality of your pond water while enjoying the peace of mind that comes with a trusted and durable filtration system.
-Input: 2 x inlets 110mm
-Output: 1 x outlet 110 mm
-Used materials: PA, stainles steel / 316, FPM seal, high pressure PVC, -silicone seal
-flow: 20,000 LPH
-Diameter drum: 38x40 cm
-Gearbox: 27Nm ,Slip clutch
-Screen panels: 70 micron stainless steel 316
-Flat jet nozzles
-Control box IP 44
-Manual control puch button
-Spray bar: high-pressure PVC 40bar
-Lid
-All components: modules, quickly changeable
-Body dimensions: 79x48x54cm (total length 79cm incl. waste collector)
-GE declaration
-2 year warranty on all parts (ex. screen elements)
-Incl. Amalgam 40watt UVC lamp
- hours counter / replace message
- Ce approval UVC/Drum body
Product features
Product features
4" Socket
1" Direct air feed
Aerated rubber disc
Robust design
Materials and care
Materials and care
PVC
